Key Features
Catalog & Equipment Workflow
- Filter equipment by manufacturer, category, specifications, availability, and price.
- Search by keyword, SKU/part number, or any active filter.
- See complete item details: description, technical specifications, photos and 3D model, price, stock on hand, and lead times.
- View all compatible accessories and optional add-ons for each unit.
AutoCAD Workflow
- Insert precise 3D equipment models directly into your drawing.
- Automatic equipment numbering/tagging, creation of production areas/departments, and grouping of equipment.
- Generate editable callouts with utility connection specs (hook-ups) right on the plan.
For user convenience, two Floating Panels have been implemented, which stay on top of all application windows. These include a panel with the most frequently used commands and a panel displaying the program’s catalog structure. Each is activated by its own button. The structure window retains the full functionality of the main catalog. The window can be resized, minimized, and closed. The panels can also be dragged to any convenient location on the screen.
The program features a unique editing method that allows designers to work in a completely new way. At the end of the generated specification, a dedicated "Connections" section has been added. Here, a table uses icons to show the connection points for each piece of equipment on the drawing, along with data from callouts. All of this data is fully editable. The specification also allows users to edit equipment numbering directly in the "Specification" tab. As a result, the designer can review and modify each connection point not in the AutoCAD drawing itself, but in this new table. All changes are automatically updated on the drawing itself.
Innovation & Efficiency
EquipCaD automates the critical steps of a foodservice and retail design workflow—cutting project prep time and boosting accuracy. Thanks to its integration with the Equip.me platform, you work from live data on equipment, stock levels, suppliers, prices, and delivery timelines.
EquipCaD packs numerous smart, field-tested innovations that make daily work easier for professional designers and can reduce project time by up to threefold.
